Daewoo SDA1609 - Using the Oven

10
32L Electric Oven with Hot Plates
Model No. SDA1609
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Hot Plate Control (3)
OFF
Large Hot Plate only
Small Hot Plate only
Both Hot Plates
Oven Function Control (5)
OFF
Lower heating element only
Upper heating element only
Both heating elements
Using the Oven
1. Place the Oven on a solid level, heat resistant surface, ensure that the
ventilation outlets are not obstructed.
2. Place the food to be cooked on the Grill Rack or on the Baking Tray.
3. Close the Door.
4. Rotate the Temperature Control (4) to the desired temperature from 100°C to
230°C.
5. Rotate the Oven Function Control (5) to select the upper heating element, the
lower heating element or a combination of both.
6. Rotate the Timer Control (6) to the desired time up to 60 minutes. The Oven
will then power up and the Power Indicator (7) will illuminate.
7. At the end of the cooking time a bell will sound and the appliance will switch
off.
