Vehicle identification
WARNING! The Electric Vehicle is equipped with high-voltage
components and wiring. Not following these instructions can result in
severe personal injury or death.
– Only work on an Electric Vehicle when the high-voltage circuit is
isolated. See procedure 'Shutting down high-voltage circuit'.
WARNING! Avoid contact with the high-voltage components and the
orange cables with their connectors until the high-voltage circuit has
been shut down.
1 Battery string
2 Electric motor
3 Charge plug
WARNING! Next to these components the vehicle is also equipped
with a high-voltage box containing high-voltage components. The
high-voltage box is located under the cabin. Exposure to high voltage
can result in serious personal injury or death.
