28
Stabilising the vehicle
4.1 SEAT ADJUSTMENT
NOTE: Before removing the seat, be aware of the safety instructions if the
vehicle is equipped with an airbag and therefore an automatic safety belt
tensioner.
NOTE: The seat can be adjusted if the vehicle air pressure is at least 7 bar.
Seat settings
1 Backrest angle adjustment.
2 Seat height adjustment.
3 Seat tilt adjustment
4 Quick down.
5 Vertical seat damper.
6 Seat length adjustment.
7 Seat cushion length adjustment.
8 Armrest.
9 Safety belt height adjustment.
10 Seat heater.
11 Lumbar support adjustment.
12 Lateral support adjustment.
13 Seat ventilation
14 Shoulder support adjustment.
G001947
9
13
10
4
3 2
6
5
7
14
8
12
11
1
4. Quick down
Knob down (seat in driving position): the seat drops to its
lowest position.
Knob up (with lowered seat): the seat rises to the last height
adjustment.
3. Seat tilt adjustment
2. Seat height adjustment
DW83211801.book Page 28 Wednesday, February 12, 2020 11:04 AM
