26
Securing the vehicle
A sticker with the airbag symbol on the
windscreen identifies vehicles
equipped with an airbag and safety belt
tensioner system.
In addition, there is an identification
'AIRBAG' visible (A) on the steering
wheel. A vehicle equipped with an
airbag also has an automatic safety belt
tensioner.
1 Safety belt tensioner
The automatic safety belt tensioner is
fitted on the rear side of the driver's and
co-driver's seat behind the seat covers.
Safety instructions
– Do not place any objects near undeployed airbags.
– Before any work is carried out on an airbag system:
1. the ignition must be switched off.
2. the main switch must be turned off.
3. the battery clamp must be removed from the negative pole.
4. wait at least 30 seconds.
– Never disconnect an electrical connector in the airbag or safety belt tensioner
circuits if the electronic control unit is energised.
G001312
1
