DAF XG+ - 3.1.4 Airbag Safety Systems

Terminals where the battery charger
can be connected are found on the
lower side of the battery box or on the
left side behind a cover.
Remove the cover (1) and connect the
positive pole (+) of the battery charger
to the positive pole (+) first. Then con-
nect the starter cable to the negative
pole (–).
After charging, switch off the battery
charger and then disconnect the nega-
tive pole (–) and subsequently the posi-
tive pole (+) and reinstall the covers.
D005550-2
1
2
D005551-2
1
2
3.1.4 Airbag
D005553
A
WARNING!
Airbag modules and safety belt tensioners are pyrotechnic sys-
tems and contain an explosive charge.
15
Securing the vehicle
11
15
19
14
13
18
10
12
17
9
16
20
8
7
2
5
3
6
4
1
