leads to automatic engagement of the park brake. This can lead to
dangerous situations.
– Turn the ignition key so that the steering wheel is released (unless the
vehicle is in a hoist).
– If there is insufficient pressure in the air reservoirs, release the park brake.
See section 'Releasing the park brake'.
– To prevent damage to the gearbox, always disconnect the prop shaft from
the differential.
CAUTION:
– Always disconnect the prop shaft when towing.
If the prop shaft remains connected during towing, the gearbox
may be seriously damaged.
If the differential is damaged:
– Hoist the vehicle at the rear and lock the steering wheel in the straight-
ahead position.
– In vehicles without oil-lubricated rear hubs, the axle shaft can be removed
on both sides.
Installing the towing eye
1 Release the locking button.
2 Take away the cover.
Remove the front plate cover plate at the left-hand or right-hand side by pulling
it forward (A).
1 Remove the rubber cover.
2 Screw in the towing eye fully
so the entire thread is used.
3 Then turn the towing eye
anti-clockwise (maximum 90
degrees) so the towing bar
can be attached to the towing
eye.
51
Towing information
11
15
19
14
13
18
10
12
17
9
16
20
8
7
2
5
3
6
4
1
