11
Users can be added to the system and access levels assigned with the Access section of the SmartPSS software. To add a new
user follow the steps below.
Enter the user menu by clicking on the User Menu icon .
To add a user click the new user button at the top of the SmartPSS interface.
Input the users details including ID, name, department, password and valid date range. The ID eld is a unique ID given to each
user, no two users can share the same ID.
When adding a Mifare card or fob to a user, rst connect the ASM100 enrolment reader to the computer via USB. Alternatively, any
card readers connected to the controller can be used to scan a user card for enrolment purposes. To choose the type of reader
to be used, select a reader device from the Card Issuer dropdown box.
Once the Card No eld shows the message: “Card Reader Ready”, the users card can be scanned which will assign the unique
card ID to the user. Left click the Card No eld, an audilble tone can be heard. Place the card over the reader, another audible
tone can be heard which confi rms the reader has scanned the card successfully. The unique card ID is now displayed in the Card
No eld.
Users can be organised by department, to add a new department right click the area in the left window pane and select Add
Department. Enter a name for the department and click Save.
Adding Users
