Dahua Technology ASI1212D User Manual

2
Tel: +44 (0)1457 874 999 | Fax: +44 (0)1457 829 201 | Email: sales@cop-eu.com | Online: www.cop-eu.com
Dahua access controllers can be used in multiple installations scenarios with options for one door, two door or four door controllers
and one way or two way access.
The example below is based on a one door one way system.
Lock
Reader
Push Exit
Emergency Exit
INOUT
Controller
One Way Access Example
Reader
Lock
WIRING CONFIGURATION - ACS CONTROLLERS

Dahua Technology ASI1212D Specifications

General

Brand	Dahua Technology
Model	ASI1212D
Category	IP Access Controllers
Language	English
