Dahua Technology ASI1212D - WIRING CONFIGURATION - ASI1212 D; Stand Alone Access Example

4
Tel: +44 (0)1457 874 999 | Fax: +44 (0)1457 829 201 | Email: sales@cop-eu.com | Online: www.cop-eu.com
The ASI1212D is a standalone two way controller with built in keypad, card & fi ngerprint readers. This unit supports a single door with
the option to add an external reader for use as a two way system.
The example below is based on a one way system.
Stand Alone Access Example
Lock
Reader
Push Exit
Emergency Exit
INOUT
Controller
Reader
Lock
WIRING CONFIGURATION - ASI1212D
