User’s Manual
113
Privacy masking
Configure the settings for the covered area parameters.
Covered area parameters
Parameter
Description
Channel
In the
Channel
list, select the channel that you want to configure the
settings for.
Live
Preview: Select the
Live
checkbox to apply the configured covered block
to the selected channel window in the live view screen.
Record: Select the
Record
checkbox to apply the configured covered
block to the selected channel window during recording.
To configure covering block, do the following:
1. Select the
Live
checkbox or the
Record
checkbox, or select the
both. The "1, 2, 3, 4" buttons are activated.
2. Click the buttons to select blocks.
3. A triangle solid black block is displayed.
4. Drag the block to the area that you want to cover and adjust the
size of the block. You can configure total 4 covered blocks.
Record
Click Apply to complete the settings.
5.5.7 Configuring Channel Type
You can configure the channel type as Analog or IP channel.
Select Main Menu > CAMERA > Channel Type.
