2 Cable
Waterproof all the cable joints with insulating tape and waterproof tape to avoid water damage
and prevent short circuits from occurring. For details, see the FAQ manual.
Figure 2-1 Cables
Table 2-1 Cable information
No. Port Name Description
1 12 VDC power port
Inputs 12 VDC power. Be sure to supply power as instructed in
the manual.
The device might become damaged or behave abnormally if
power is not correctly supplied.
2 Ethernet port
●
Connects to network with network cable.
●
Provides power to the device with PoE.
PoE is available on select models.
Quick Start Guide
2
