Dahua HD Mini IR Waterproof Bullet Network Camera Quick Start Guide
1
1 Framework
1.1 Device External Cable
Note
The following figure is for reference only; it is used to know the function of cable port. Different
devices may have different cable.
Figure 1-1
Please refer to Table 1-1 for detailed information.
SN
Port name
Connector
Function description
1
Network
port
Ethernet
port
Connect to standard Ethernet cable.
Note
Some devices do not support PoE power
supply.
2
Power input
port
-
Power port. Input DC 12V.
Caution
It may cause damage to the device if it fails
to power the device according to the label
description.
Table 1-1
1.2 Framework and Dimension
Note
The following figures are for reference only, which are used to know the device dimension.
Please refer to Figure 1-2 for more details.
Figure 1-2
