Dahua ASI1201E-D User Manual

User Manual
Code: ASI1201E-D
ACCESS CONTROLLER ASI1201E-D DAHUA
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-10-05 ASI1201E-D 2/5
Cards support: Unique EM 125kHz
Reading distance of prox-keys: max. 6 cm
Autonomous operation:
Keyboard built-in:
Communication:
• Ethernet
• RS-485
• Wiegand
Tamper output:
Power supply: 9 ... 15 V DC
Maximal current consumption: 200 mA
Main features:
• 30000 indexed users,
• Events memory : 150 000,
• Touch control keys,
• Blue backlight of the keys,
• 6 access groups
Operation temp: -30 °C ... 60 °C
Permissible relative humidity: ≤ 95 % (non-condensing)
Housing: Plastic
Color: Black

Dahua ASI1201E-D Specifications

General

Brand	Dahua
Model	ASI1201E-D
Category	IP Access Controllers
Language	English
