Dahua DH-IPC-HFW2431SP-S-0360B User Manual

Cable 1
1 Cable
 Cable type might vary with different devices, and the actual product shall prevail.
 Please waterproof all the cable joints with insulating tape and waterproof tape to avoid
short circuit and water damage. For the detailed operation, see the FAQ Manual.
Cable list Figure 1-1
For more information about cable ports, see Table 1-1.
Table 1-1 Cable information
No.
Port Name
Description
1
Ethernet Port
Connects to network with network cable.

Provides power to the device with PoE.

PoE is available on select model.
2
12V DC
power input
Inputs 12V DC power. Please be sure to supply power as instructed in the
manual.
Device abnormity or damage could occur if power is not supplied correctly.

Dahua DH-IPC-HFW2431SP-S-0360B Specifications

General

Brand	Dahua
Model	DH-IPC-HFW2431SP-S-0360B
Category	Security Camera
Language	English
