Dahua DH-XVR5104C-X User Manual

Local Configurations 98
Click Apply to save the settings. Step 3
Click Copy to copy the settings to other channels.
5.4.2 Working with PTZ Control Panel
PTZ control panel performs the operations such as directing camera in eight directions,
adjusting zoom, focus and iris settings, and quick positioning.
Basic PTZ Control Panel
Right-click on the live view screen and then select PTZ. The PTZ control panel is displayed.
See Figure 5-57.
Figure 5-57
The functions with buttons in gray are not supported by the system.
Parameter
Description
Speed
Controls the movement speed. The bigger the value is, the faster the
movement will be.
Zoom
: Zoom out.
: Zoom in.
Focus
: Focus far.
: Focus near.
Iris
: Image darker.
: Image brighter.
PTZ movement
Supports eight directions.

Dahua DH-XVR5104C-X Specifications

General

Operating System	Embedded Linux
Analog Camera Input	4
HDCVI Camera Input	4
AHD Camera Input	4
TVI Camera Input	4
Audio In/Out	1/1
Two-way Talk	Yes
Resolution	1080P
OSD	Yes
USB Interface	2 x USB 2.0
Weight	1.5kg
Channels	4
Record Rate	25/30fps
Record Mode	Alarm
Record Interval	1-60 minutes
Video Output	1 HDMI, 1 VGA
Display Interface	HDMI, VGA
Ethernet	1x RJ45
Network Functions	P2P
Smart Phone	iOS/Android
Internal HDD	1 SATA, up to 6TB
Power Supply	DC12V
Power Consumption	< 10W
Working Environment	-10°C ~ +55°C
Operating Temperature	-10°C ~ +55°C
Operating Humidity	10% to 90%
