Dahua DHI-ITC215-PW6M-IRLZF-B User Manual

User’s Manual
2
Table 2-3 Cable connection description
No.
Port
Function
Description
1 LAN Ethernet port
Connects to standard Ethernet, supports PoE
power supply.
2 AUDIO OUT Audio output port
The Camera sends out audio signal through this
port.
3 AUDIO IN Audio input port The Camera gets audio signal through this port.
4 BNC Video output port
The Camera sends out video signal through this
port.
5 DC 12V Power inputport
Inputs 12V DC power. Please be sure to supply
power as instructed.
Device damage will occur if power is not supplied
correctly.
6 RS-485 RS-485 port
Yellow: RS-485_A1
Orange: RS-485_B1
7 ALARM Alarm port
Alarm output, connecting to barrier, and alarm
output devices such as alarm light.
 Brown: ALARM_OUT1
 Green: ALARM_OUT_GND1
 Red: ALARM_OUT2
 Black: ALARM_OUT_GND2
Alarm input, connecting to vehicle detector, IR
detector, induction coil, and more.
 Blue: ALARM_IN1
 White: ALARM_IN2
 Yellow: ALARM_IN3

Gray: ALARM_IN_GND
8 AC 24V Power input port
Inputs 24V AC power. Please be sure to supply
power as instructed.
Device damage will occur if power is not supplied
correctly.
