User’s Manual
30
Step 2 Set Begin Time and End Time, and then set the Direction (vehicle movement
direction, including Double, Obverse, Reverse, and Unknown).
Step 3 Click Search to search for the plates that meet the search conditions.
Step 4 Click Export, and then select storage path to export the results to PC.
4.5 Setup
You can configure several parameters such as ITC, camera, network, event, storage, system,
and system information.
4.5.1 ITC
You can set intelligent parameters of the Camera.
4.5.1.1 Detection
4.5.1.1.1 Snapshot
You can set snapshot rule of the Camera.
Step 1 Select Setup > ITC > Detection > Snapshot.
Figure 4-29 Snapshot
Step 2 Configure the parameters.
Table 4-12 Description of capture parameters
Work Mode
Coil: Use coil to take snapshots.
Video: Use video to take snapshots.
Mixmode: Use coil + video to take snapshots.
Amount
It can take 1–2 snapshot(s).
