Dahua DHI-NVR608R-64-4KS2 User Manual

16
Figure 2-8
The NVR608-64-4KS2/NVR608-128-4KS2 general series rear panel is shown as in Figure 2-9.
Figure 2-9
The NVR608-64-4KS2/NVR608-128-4KS2 redundant power series rear panel is shown as in Figure 2-10.
Figure 2-10
Please refer to the following sheet for detailed information.
SN Function SN Function
1 Power socket 2 Alarm input/alarm output/RS485 port.
2 RS232 port 4 Audio output
5 Audio input 6 VGA port
7 Network port 8 HDMI port
