Dahua DSS7016D-S2 User Manual

2
1.2.1 Front Panel
Figure 1-1 Front panel
Table 1-2 Front panel description
No.
Port or Button
Description
1
Power button
Press the button to start the server. Long press it
to shut down.
2
Hard drive indicator
light
The light flashes during disk-reading.
3
Alarm indicator light
The blue light flashes when the server triggers an
alarm.
4
Network indicator light
The blue light flashes when network is well
connected.
5
USB 2.0 port
2 ports, white
6
Panel locks
Use key to unlock the front panel before taking it
off the server.
7
Tab and screw hole
Used to fix the server into the standard cabinet.
8
LCD
7-inch display for local system operations.
