11
User’s Manual
The above content is for reference only, and everything is subject to actual conditions.
Table 3-3 Indicator description (1)
Table 3-3 OSD Buttons (2)
LED indicator light
Name Description
The blue light indicates that the power supply is normal and
the monitor is running normally.
The red light indicates no video source, no horizontal or
vertical signals, or too low a voltage.
The light is off when the screen is turned off.
Menu button: Press to display OSD menu and enter sub-menus.
Down button: Move down in the menu/quickly adjust the game crosshairs.
Up button: Move up/quickly adjust contextual model.
Exit key: Returns to the previous menu/
quickly adjust the input signal.
Power button: Press to turn monitor on/off.
OSD Button Function
Figure 3-3 Indicator and button display
DHI-LM34-E330C
