16
User’s Manual
DHI-LM34-E330CA
The above ports are for reference only, the actual ports of different types of monitors may be slightly different
from the ports in the figure, and everything is subject to the ports and functions of the actual product.
Table 4-4 Input and output ports
Port Function
x2/ Use the DP cable to connect to a desktop PC.
DP
AUDIO
AC
x2/ Use the HDMI cable to connect the HDMI IN interface of the product to the HDMI OUT
interface of a PC.
HDMI
x1/ Use to connect with external sound output devices such as headphones or earphones.
x1/ Please connect the power cable plug to the corresponding port of the monitor,
and connect the other end to a properly grounded power outlet.
Figure 4-4 Input and output interface
DP 1 AUDIODP 2HDMI 2 HDMI 1
