Network Configuration 4
Modify IP address interface Figure 2-3
Select Static mode, and then enter start IP, subnet mask, and gateway. Step 3
IP addresses of multiple devices will be set to the same if you select the Same IP
checkbox.
If DHCP server is available in the network, devices will automatically obtain IP
addresses from DHCP server when you select DHCP.
Click OK. Step 4
Logging in Web Interface 2.3
Open IE browser, then enter the IP address of the device in the address bar, and then Step 1
press Enter.
If the setup wizard is displayed, finish the settings as instructed.
Enter the user name and password in the login box, and then click Login. Step 2
For first time login, click Click Here to Download Plugin, and then install the plugin as Step 3
instructed.
The main interface is displayed when the installation is finished. See Figure 2-4.
Main interface Figure 2-4
