Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual
3
(1280*720@1fps)
Note:
The exact frame rate of extra stream 2 is decided by device max
capacity set, it is dynamic and adjustable during the range of max
capacity set.
Video Bit Rate
H.264H: 40Kbps-8192Kbps; adjustable.
MJPEG: 40Kbps-16384Kbps; adjustable and bit rate is adjustable.
Support customized setup. (The actual bit rate is subject to device
adjustable range)
Video Flip
Support mirror.
Supports flip, corridor mode function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
ROI
Supports max 4 ROI zones
Video Setup
Support parameter setup such as bright, contrast and acutance.
Video
Information
Channel title, time title, motion detect, tampering, overlay.
Lens
2.8～12mm/F1.4(manual focus)
Lens Interface
φ14 port, Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Video Tampering
Sensitivity level 1-6, each level is corresponding to the tampered zone
percentage of the video
Activation event: video storage, image snapshot, log, email function
and etc.
Recor d and Backu p
Video Priority
Manual>Video detect>Schedule
Storage
Management
Support NAS storage
Network
Wired Network
1-channel wired Ethernet port, 10/100 Base-T Ethernet
Network Protocol
Standard,HTTP,TCP/IP,ARP,IGMP,ICMP,RTSP,RTP,UDP,RTCP,SMT
P,FTP,DHCP,DNS,DDNS,PPPoE,UPnP,NTP,Bonjour,SNMP,Qos,802.
1x
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc.
Platform
Interface
Protocol
PSIA, ONVIF
General Parameter
Power
DC12V power, PoE power supply
Power
Consumption
4.5W MAX
Working
Temperature
-30℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
72*80*212.8
Weight
650g
Installation
Installation with the bracket.
