Dahua HD IR Vari-Focal Fixed Network Camera User’s Manual
2
to adjust the bright.
 Support digital WDR.
 Support video watermark function to avoid vicious video modification.
 Support dual bit streams, ACF.
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for network camera performance specification.
Model
Parameter
IPC-HFW2100R-VF
IPC-HFW2200R-VF
IPC-HFW2300R-VF
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network monitoring, local record, and remote
operation at the same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
1/2.8-inch CMOS
1/3-inch CMOS
Scan Pixel
1280(H)*960(V)
1920(H)*1080(V)
2048(H)*1536(V)
Day/Night Mode
Support day/night mode switch.
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Electronic
Shutter
Auto/Manual
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H.264/H.264H/MJPEG
Video Frame
Rate
PAL:
Main stream
(1280*960@25fps)
Extra Stream 1
(704*576@25fps),
Extra Stream 2
(1280*720@8fps)
PAL:
Main stream
(1920*1080@25fps)
Extra Stream 1
(704*576@25fps),
Extra Stream 2
(1280*720@11fps)
PAL:
Main stream
(2048*1536@20fps)
Extra Stream 1
(704*576@20fps),
Extra Stream 2
(1280*720@1fps)
Main Stream
(1920*1080@25fps)
Extra Stream 1
(704*576@25fps),
Extra Stream 2
(1280*720@11fps)
NTSC:
Main stream
(1280*960@30fps)
extra stream 1
(704*480@30fps),
Extra Stream 2
(1280*720@1fps)
NTSC:
Main stream
(1920*1080@30fps)
Extra Stream 1
(704*480@30fps),
Extra Stream 2
(1280*720@1fps)
NTSC:
Main stream
(2048*1536@20fps)
Extra Stream 1
(704*480@20fps),
Extra Stream 2
(1280*720@1fps)
Main Stream
(1920*1080@30fps)
Extra Stream 1
(704*480@30fps),
Extra Stream 2
