Local Basic Operations 106
Figure 4-83
Step 2 Configure parameters. See Table 4-20.
Table 4-20
In the Channel list, select the channel that you want to connect the PTZ
camera to.
Local: Connect through RS-485 port.
Remote: Connect through network by adding IP address of PTZ
camera to the Device.
In the Protocol list, select the protocol for the PTZ camera such as
PELCOD.
In the Address box, enter the address for PTZ camera. The default is 1.
The entered address must be the same with the address configured on
the PTZ camera; otherwise the system cannot control PTZ camera.
In the Baud rate list, select the baud rate for the PTZ camera. The default
is 9600.
