Dahua NVR5432-EI User Manual

Icon Name Function
USB 2.0 port
Connect to peripheral USB 2.0
storage device, mouse, burner and
more.
2.1.12 NVR608-32-4KS2 Series
The following gures are for reference only.
The NVR608-32-4KS2 front panel is shown as below.
Figure 2-23 Front panel
Table 2-11 Icons description
Icon
Name Function
STATUS Status indicator light
The blue light is on when the device
is working properly.
HDD HDD status indicator light
The blue light is on when the HDD
malfunctions.
NET Network status indicator light
The blue light is on when the
network connection is abnormal.
POWER Power status indicator light
The blue light is on when the power
connection is normal.
USB 2.0 port
Connect to peripheral USB 2.0
storage device, mouse, burner and
more.
2.1.13 NVR608-64-4KS2/NVR608-128-4KS2/NVR608H-XI/
NVR608RH-XI Series
The NVR608-64-4KS2/NVR608-128-4KS2/NVR608H-32-XI/NVR608H-64-XI/NVR608H-128-XI/
NVR608RH-32-XI/NVR608RH-64-XI/NVR608RH-128-XI front panel is shown as below.
User's Manual
15

Dahua NVR5432-EI Specifications

General

Model	NVR5432-EI
Video Input Channels	32
Incoming Bandwidth	320 Mbps
Outgoing Bandwidth	160 Mbps
Operating System	Embedded Linux
Two-way Talk	Yes
Multi-screen Display	Yes
OSD	Yes
Browser	IE, Chrome, Firefox, Safari
Backup Method	USB, Network
RS232	1
RS485	1
Max. User Access	128
Max Resolution	12MP
Recording Resolution	12MP (4000x3000)
Video Output	2 HDMI, 1 VGA
HDMI Resolution	4K (3840×2160)
VGA Resolution	1920x1080
Max HDD Capacity	10TB per HDD
Network Interface	2x 10/100/1000Mbps
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	-10°C to +55°C
Dimensions	440mm
Processor	Embedded processor
Video Compression	H.265/H.264
Audio Compression	G.711
Network Protocol	TCP/IP, DHCP, DNS, HTTP
Mobile Phone Access	Yes
Interoperability	ONVIF
Record Mode	Manual, Schedule, Motion, Alarm
USB	2×USB 2.0
Operating Humidity	10%
Storage	4 SATA ports, up to 16TB capacity for each HDD
Power Consumption	≤ 20W
