Dahua NVR5432-EI User Manual

No. Port Name Function
RS-485 port (A, B)
●
RS485_A port. Control cable A of the 485 device. It connects
external devices such as speed dome and PTZ.
●
RS485_B port. Control cable B of the 485 device. It connects
external devices such as speed dome and PTZ.
CTRL
Controllable 12 V power output. It is to control the on-
o alarm relay output. It can be used to control the
device alarm output. At the same time, it can also be
used as the power input source of some devices such
as alarm detector.
The
two
ports
serve as
another
group
of
alarm
output
ports.
+12 V power output port. It can provide power to some
peripheral devices such as camera and alarm device.
Make sure the power supply of peripheral device shall
be below 1 A.
8
MIC IN
Bidirectional talk input port. It is to receive analog audio signal
from devices such as microphone, sound pickup.
MIC OUT
Audio output port. It is to output analog audio signal to devices
such as sound box.
●
Bidirectional talk output.
●
Audio output on 1-window video monitor.
●
Audio output on 1-window video playback.
9 USB port
USB 3.0 port. Connect to devices such as mouse, USB storage
device and USB burner.
10 Network port
10/100/1000 Mbps self-adaptive Ethernet port. Connect to the
network cable.
11 Power input port Input power of 100-240 V and 50-60 Hz.
12 GND.
2.2.26 NVR52-16P-I/NVR52-16P-I/L/NVR52-8P-I/NVR52-8P-I/L/
NVR42-16P-I Series
These gures are for reference only.
The NVR52-16P-I/NVR52-16P-I/L series rear panel is shown as below.
User's Manual
58

Dahua NVR5432-EI Specifications

General

Model	NVR5432-EI
Video Input Channels	32
Incoming Bandwidth	320 Mbps
Outgoing Bandwidth	160 Mbps
Operating System	Embedded Linux
Two-way Talk	Yes
Multi-screen Display	Yes
OSD	Yes
Browser	IE, Chrome, Firefox, Safari
Backup Method	USB, Network
RS232	1
RS485	1
Max. User Access	128
Max Resolution	12MP
Recording Resolution	12MP (4000x3000)
Video Output	2 HDMI, 1 VGA
HDMI Resolution	4K (3840×2160)
VGA Resolution	1920x1080
Max HDD Capacity	10TB per HDD
Network Interface	2x 10/100/1000Mbps
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	-10°C to +55°C
Dimensions	440mm
Processor	Embedded processor
Video Compression	H.265/H.264
Audio Compression	G.711
Network Protocol	TCP/IP, DHCP, DNS, HTTP
Mobile Phone Access	Yes
Interoperability	ONVIF
Record Mode	Manual, Schedule, Motion, Alarm
USB	2×USB 2.0
Operating Humidity	10%
Storage	4 SATA ports, up to 16TB capacity for each HDD
Power Consumption	≤ 20W
