Dahua VTO6000A User Manual

错误!使用“开始”选项卡将 Heading 1 应用于要在此处显示的文字。 27
Add single room number
Configure room information. See Table 4-3.
Table 4-3 Room information
Parameter
Description
First Name
Enter the information you need to differentiate each room.
Last Name
Nick Name
Room No.
The room number you planned.
 If you use multiple VTH devices, the room number of the
master VTH should be "room number#0", and the room
number of the extension VTH should be "room
number#1", "room number#2", and so on.
 You can have 9 extension VTH devices at most for one
master VTH.
Register Type
Select public, and local is reserved for future use.
Register
Password
Keep the default value.
Click Save.
The added room number is displayed. Click to modify room information, and click
to delete a room.
Verifying Configuration
4.4.1 Calling VTH from VTO
Press the call button on the VTO.

Dahua VTO6000A Specifications

General

Operating System	Embedded LINUX
Video Frame Rate	25fps
Audio Output	Built-in Speaker
Video Compression	H.264
Audio Compression	G.711
Bidirectional Talk	Support Dual-way Bidirectional Talk
IC Card Reader	Support
Unlock Mode	Remote, password, card
Network Interface	10M/100M Ethernet
Network Protocol	TCP/IP
RS485	Yes
Alarm Output	1 channel
Door Control	Yes
Exit Button	Yes
Door Status Detection	Yes
Card Capacity	10000
Tamper Switch	Yes
Power Supply	DC 12V
Operating Temperature	-30°C to +60°C
Working Humidity	10% to 90% (non-condensing)
