Figure 1- 4 VTO6110B and VTO6110BW
No.
Component
Name
Note
1
Vandal
Proof
Switch
It will generate alarm sound and report to the center once
VTO is forced to leave the wall.
2
Network
Port
Plug in network cableRJ45 port.
3
Power
Connect to 12V DC.
4
RS485 Port
May connect to access control extension module.
5
Speaker
Audio output
VTO6210B’s rear panel is as in Figure 1- 5 VTO6210B.
