Daikin 4MKS90EVMA - Top Panel Removal

Si12-794 Removal of Outer Panels
Removal Procedure 3
2
Slide the suction grille
downward to unfasten
the 3 top hooks.
3
Remove the suction
grille.
2. Remove the top panel.
1
Remove the 4 screws
on the back and the
screw on the left side
panel.
Step
Procedure Points
Hook
(
R14613
)
(R6372)
Top panel
Left side panel
(R6373)
