Daikin 4MKS90EVMA - Front Panel (1) Removal

Si12-794 Removal of Outer Panels
Removal Procedure 7
3
Remove the front panel
(2).
5. Remove the front panel
(1).

Remove the discharge grille
and outdoor fan first to
remove the front panel (1).
1
Remove the 4 screws
on the discharge grille.
2
Pull the bottom of the
discharge grille.
Step
Procedure Points
(R6383)
(R10375)
(R10376)
Front
Panel (1)
Discharge grille
(R10377)
