English 15
Mode
No.
Note) 1
FIRST
CODE
NO.
Description of setting
SECOND CODE NO. Note) 2
01 02 03 04
12 (22)
1
ON/OFF input from outside (setting
for when forced ON/OFF is to be
operated from outside).
Forced OFF
ON/OFF
operation
———— ————
2
Thermostat differential changeover
(setting for when using remote
sensor).
1°C 0.5°C ———— ————
13 (23)
0
High air outlet velocity (for high
ceiling applications).
≤ 2.7m > 2.7 ≥ 3.0m > 3.0 ≥ 3.5m
————
1
Selection of airfl ow direction (setting
for when a blocking pad kit has
been installed).
4-way fl ow 3-way fl ow 2-way fl ow ————
3
Selection of airfl ow function (setting
for when using a decoration panel
for outlet).
Equipped Not equipped ———— ————
4 Airfl ow direction range setting. Upper
Normal
Lower ————
6
Setting the external static pressure
(setting according to the connected
duct resistance) (for FHYK, follow
the high ceiling setting)
Normal
(Normal)
High static
pressure
(High ceiling)
Low static
pressure
————
————
————
15 (25) 3
Drain pump operation with
humidifying.
Equipped Not equipped ———— ————
1c
1
Thermostat sensor in remote
controller (for limit operation and
Home leave function only)
Not use Use ———— ————
3 Permission level setting Level 2 Level 3 ———— ————
1e 2 Home leave function Not permitted Permitted ———— ————
Notes) Though setting is performed totally in the group, set Mode No. in the parenthesis when 1.
individual setting per indoor unit or checking after the setting should be performed.
SECOND CODE NO. at factory shipment is set to “01”. However for the following cases it is 2.
set to “02”.
Airfl ow direction range setting (except round fl ow cassette) ●
Thermostat sensor in remote controller (SkyAir only) ●
Thermostat sensor in remote controller for limit operation and Home leave function only ●
Any function which the indoor unit does not have is not displayed.3.
01_EN_EM08A086.indd 1501_EN_EM08A086.indd 15 4/7/2009 7:32:15 PM4/7/2009 7:32:15 PM
