Installation manual BRC1E52A7
7
4PW71264-1 – 10.2011
3-5-2 Left outlet
PC-board
Lower case
Upper case
Indoor unit
P1P2
3-5-3 Upper outlet
Install attached
wiring retainer to
prevent wiring pinch
according to left
figure.
PC-board
Indoor unit
Wiring retainer
Wiring retainer
Upper case
Lower case
Upper case
Wiring
Cross-section -
P1P2
3-5-4 Upper center outlet
PC-board
Indoor unit
Wiring retainer
Upper case
Lower case
P1P2
