English 11
Installation
5 Installation of Wireless LAN adapter
BRP069B41/B45
Install WLAN adapter inside the indoor unit. For more details about
installation of WLAN adapter to your model please visit http://www.
onlinecontroller.daikineurope.com.
BRP069B42/B43/B44
Install the WLAN adapter outside the indoor unit. There are two ways
of installation A and B.
TYPE A
Position of the WLAN adapter on the wall/surface is xed by screws.
In this case double face tapes located in accessory set are not
neccessary to x the holder.
1. Fix the WLAN holder on the wall/surface with 2 screws located in
accessory set.
2. Attach the WLAN adapter to the holder by sliding into it.
For more details about installation of WLAN adapter to your model
please visit http://www.onlinecontroller.daikineurope.com.
Installation
Work
Holes for screws
Holder
To Next Page
