Daikin DBC - Page 2

2


FLA MCA MOP FLA MCA MOP
0270L01170 1.7 2.1 3.7 1.5 1.9 3.4
0270L01137 3.3 4.1 5.4 3.0 3.8 4.9
PART
NUMBER
208V, 1PH, 60Hz
230V, 1PH, 60Hz
FLA MCA MOP
0270L01171 0.5 0.6 1.1
0270L01138 1.0 1.3 1.6
460V, 3PH, 60Hz
PART
NUMBER
Table2-ElectricalData
FLA
MCA
MOP
N/A
Toinstallthehorizontalpowerexhaust,perform
thefollowingprocedures:
 󰀨
󰀨
NOTE:Beforeinstalling,ensurevoltageof
powerexhaustagreeswithpowersupplytothe
equipment.
CAUTION
UNIT DAMAGE HAZARD
FAILURE TO FOLLOW THIS CAUTION MAY RESULT IN EQUIPMENT DAMAGE.
BE CAREFUL TO ROUTE WIRES TO AVOID PINCHING OR CUTTING DURING
ASSEMBLY. IT CAN BE DIFFICULT TO PROTECT THE WIRES WHILE ATTACHING
THE POWER TO THE UNIT.
CAUTION
CUT / SEVER HAZARD
Failure to follow this cauon may result in personal
injury.
Sheet metal parts may have sharp edges or burrs. Use
care and wear appropriate protecve clothing, safety
glasses and gloves when handling parts and servicing
air condioning equipment.
 




 



 

SHIPPING BLOCKS
POWER EXHAUST ASSEMBLY
Figure1-ShippingBlock
 

 


POWEREXHAUSTWIRINGFORW7220
CONTROLLER
 


 



 


 

