3
LOW VOLTAGE WIRE HARNESS
HIGH VOLTAGE WIRE HARNESS
POWER EXHAUST ASSEMBLY
TO HV POWER BLOCK
ECONOMIZER
PULL WIRE HARNESSES
THRU WIRE GROMMET
Figure2–3-6TonPowerExhaustWiring
LOW VOLTAGE WIRE HARNESS
HIGH VOLTAGE WIRE HARNESS
POWER EXHAUST ASSEMBLY
TO HV POWER BLOCK
ECONOMIZER
PULL WIRE HARNESSES
THRU WIRE GROMMET
Figure3–7½-12½TonPowerExhaustWiring
 


Figure4-SinglePointConnection
NOTE:Iftheunitisnotequippedwithsinglepoint
connection,externalpowermustbesuppliedto
thepowerexhaust.DONOTCONNECTTOUNIT
POWER.UnitMCAandMOPcalculatedbasedon
factoryinstalledequipment,socomponentsmay
notbesizedappropriately.
 




Figure5-SinglePointConnectionLeads
