PRODUCT IDENTIFICATION
6
MODEL: DM97MC REV AA
Equipment Type Daikin Brand Residential Gas Furnace
Heating Stages Modulating (35% - 100% of rated input)
Cooling Stages Two
Control Type ClimateTalk
™ or Conventional 24 Volt
Blower Motor Type 4 Wire Variable Speed ECM
DM97MC
0603BN 0803BN 0804CN 1005CN 1205DN
Installation Positions
UF, Hor L/R UF, Hor L/R UF, Hor L/R UF, Hor L/R UF, Hor L/R
Installation Positions
UF, Hor L/R UF, Hor L/R UF, Hor L/R UF, Hor L/R
UF, Hor L/R
BTUH Input Range (X 1000)
21 - 60 28 - 80 28 -80 35 - 100 42 - 120
A/C Capable Tons
1.5 - 3 1.5 - 3 2 - 4 2 - 5 2 - 5
Cabinet Hight "
34.5 34.5 34.5 34.5 34.5
Cabinet Width "
17.5 17.5 21 21 24.5
Heating CFM @ 100% Firing Rate
1059 1316 1337 1870 1940
Draft Inducer
3
Ø Variable Speed
Gas Valve 24 VAC, Modulates by Pneumatic signal
24 VAC Heating Inputs W1 / W2
24 VAC Cooling Inputs Y1 / Y2
Primary Heat Exchanger Stainless Steel
Accessory Terminals EAC terminal, HUM IN / HUM OUT terminals
Gas Line Entry Left or Right
Revision Attributes First revision of 34.5" modulating up flow furnace
MODEL: DC97MC
REV AA
Equipment Type Daikin Brand Residential Gas Furnace
Heating Stages Modulating (35% - 100% of rated input)
Cooling Stages Two
Control Type ClimateTalk
™ or Conventional 24 Volt
Blower Motor Type 4 Wire Variable Speed ECM
DC97MC
0603BN 0803BN 0804CN 1005CN
Installation Positions
CF, Hor L/R CF, Hor L/R CF, Hor L/R CF, Hor L/R
BTUH Input Range (X 1000)
21 - 60 28 - 80 28 -80 35 - 100
A/C Capable Tons
1.5 - 3 1.5 - 3 2 - 4 2 - 5
Cabinet Hight "
34.5 34.5 34.5 34.5
Cabinet Width "
17.5 17.5 21 21
Heating CFM @ 100% Firing Rate
950 1146 1325 1779
Draft Inducer
Gas Valve
24 VAC Heating Inputs
24 VAC Cooling Inputs
Primary Heat Exchanger
Accessory Terminals
Gas Line Entry
Revision Attributes First revision of 34.5" modulating counter flow furnace
Left or Right
3
Ø Variable Speed
24 VAC, Modulates by Pneumatic signal
W1 / W2
Y1 / Y2
Stainless Steel
EAC terminal, HUM IN / HUM OUT terminals
