5. BACnet® Server Gateway Points List
6 Quick User Guide DCM014A51
5. BACnet® Server Gateway Points List
5.1 iTM System Points List
The following are iTM system points that link to the iTM's control logic. Each iTM has only one set of system
points. Refer to iTM BACnet® Server Design Guide– Part 2 for points description.
Instance
No.
Object_Name Type
Inactive
Active
Remarks
Text-1
Text-2
Text-3
Text-4
Text-5
Text-6
Text-7
1
Enable iTM Schedule
Operation
BO Disable Enable
2
Enable iTM
Auto-Changeover
Operation
BO Disable Enable
3
Timed Override Minutes
MV
30
60
90
120
150
180
4
System Forced Off
BO
Inactive
Active
5.2 Indoor Unit Points List
The following are indoor unit control and monitoring points. Each indoor unit group shall have one set of these
points. Refer to iTM BACnet® Server Design Guide– Part 2 for point description.
Instance
No.
Object_Name Type
Inactive Active
Remarks
Text-1 Text-2 Text-3 Text-4 Text-5 Text-6 Text-7 Text-8
1 Occupancy Mode MO Unocc Occ Standby
2 Unit On_Off Status BI Off On
3 Alarm Status BI Normal Alarm
Sets error
code in the
4 Operation Mode MV Cool Heat Fan Dry
See (1)
below.
5 Room Temperature AI *1, *2
6
Occ Cooling
Setpoint
AV *1, *2
7
Occ Heating
Setpoint
AV *1, *2
8
Unocc Cooling
Setpoint
AV *1, *2, *3
9
Unocc Heating
Setpoint
AV *1, *2, *3
10
Max Cooling
Setpoint
AV
*1, *2, *4
11
Min Cooling
Setpoint
AV
12
Max Heating
Setpoint
AV
*1, *2, *4
13
Min Heating
Setpoint
AV
14
Min Setpoint
Differential
AV *1, *2
15
Cooling & Heating
Setpoint Tracking
BV Disable Enable
Continued on next page.
