5. BACnet® Server Gateway Points List
DCM014A51 Quick User Guide 7
Instance
No.
Object_Name Type
Inactive Active
Remarks
Text-1 Text-2 Text-3 Text-4 Text-5 Text-6 Text-7 Text-8
16 Fan Speed MV Low Reserved Medium Reserved High Reserved Reserved Auto
17 Airflow Direction MV P0 P1 P2 P3 P4 Reserved Reserved P7
18
Timed Override
Operation
BV Disable Enable
19
Current Unit
Operation
MI Off Normal Override Setback
20
Remote Controller
Prohibit
MV Permit Prohibit Stop Only
21
Remote Controller
Prohibit
(Operation Mode)
BV Permit Prohibit
22
Remote Controller
Prohibit
(Setpoint)
BV Permit Prohibit
23 Filter Sign Status BI Normal Alarm
24 Filter Sign Reset BV Reset Alarm
25 Indoor Fan Status BI Off On
26
Communication
Status
BI Normal Alarm
27 Thermo-on Status BI Off On
28 Compressor Status MI Off On
Defrost/
Hot Start
29 Aux Heater Status BI Off On
30 Forced Thermo-off BV Disable Enable
31
Indoor Unit
Changeover Option
BI
Not
Available
Available
*1: The unit of temperature (Celsius or Fahrenheit) follows the iTM locale (regional settings).
*2: The number of valid digits for each object is shown in the table below. If a value entered from BMS has a higher precision than the
number of significant digits of an object, the digits after the significant digits are rounded.
(For example, when OccCoolingSetpoint is "75.55" in degrees Fahrenheit, round it to "76".)
Regarding values in commands sent from the BMS, the iTM rounds them off to the number of the significant digits.
(For example, if the value in a command for OccCoolingSetpoint is "75.55" in degrees Fahrenheit, it is rounded to "76".)
