Daikin DPS028A - Page 8

Figure 3: Roof Curb Assembly (DPS 007–015)
1
A
F
D
B
C
E
A
E
RETURN
AIR
SUPPLY
AIR
FRONT SIDE
RIGHT SIDE
BACK SIDE
LEFT SIDE
NOTE: 1. Check submittal drawing for gas/water/electrical/supply/return air opening
Horizontal above the roof gas connection only
Standard Roof Curb – Medium Cabinet
DPS 007–012 Roofcurb with ERW Certi ed Drawing
McQuay International certi es that its equipment will conform to this drawing and McQuay’s
published speci cations, subject to its published warranty. Purchaser must determine that the
equipment is  t and suf cient for the job speci cations. No change to this drawing may be made
unless approved in writing by McQuay. www.DaikinMcQuay.com © 2012 McQuay International
Model: DPS
Date:
Unit Tag:
Units: Sheet: __ of __
Curb Detail
A–A
2"×4"
Nailer
A A
2.0"
Typ.
4.0"
14.0"
or
24.0"
34.88
Inside
48.38
Inside
81.5
Inside
13.5
Inside
30.5
Inside
Supply
Opening
Return
Opening
Electrical
Entrance
24.25
2.0
3.4
6.9
8.8
Roof Curb for ERW – Medium Cabinet
DPS 007–012 Roofcurb with ERW Certi ed Drawing
McQuay International certi es that its equipment will conform to this drawing and McQuay’s
published speci cations, subject to its published warranty. Purchaser must determine that the
equipment is  t and suf cient for the job speci cations. No change to this drawing may be made
unless approved in writing by McQuay. www.DaikinMcQuay.com © 2012 McQuay International
Model: DPS
Date:
Unit Tag:
Units: Sheet: __ of __
Curb Detail
A–A
2"×4"
Nailer
A A
2.0"
Typ.
4.0"
14.0"
or
24.0"
34.88
Inside
48.38
Inside
101.5
Inside
13.5
Inside
30.5
Inside
Supply
Opening
Return
Opening
Electrical
Entrance
20.0
24.25
2.0
3.4
6.9
8.8
IM 1125-7 • REBEL ROOFTOPS 8 www.DaikinApplied.com
MeChanICal InsTallaTIon
