Daikin EBLA11DAV3 - Page 320

6 | Technical data
Service manual
320
EBLA09~16DA + EDLA09~16DA
Daikin Altherma 3 M
ESIE20-06A – 2021.03
English Translation
F1B # Overcurrent fuse backup heater
K1A, K2A * High voltage Smart Grid relay
K1M Safety contactor backup heater
K3M * Contactor booster heater
Q1DI # Earth leakage circuit breaker
TR1 Power supply transformer
X4M * Terminal strip (booster heater power
supply)
X6M # Terminal strip (power supply at client
side)
X9M Terminal strip (integrated backup
heater power supply)
X10M * Terminal (high voltage Smart Grid)
X*A Connector
X*M Terminal strip
