Network accessible parameters
Conguration registers
The table below shows the addresses of the control parame-
ters resident on the INN-FR-B32 e EKWHCTRL0 board and the
EKRTCTRL1 and EKWHCTRL1 wall-mounted control panel.
In the typ column, it is specied if these registers are read
only (R) or writable (R/W). Please take into account the multi-
plication factor mlt during reading of the parameters.
The limit values must be respected!
Reg. Mnemonic Limit values Description typ mlt Std. value
000 T1 0...100.0 °C Air temperature R 0.1 -
001* T2 0...100.0 °C Hot water temperature H2 R 0.1 -
008 SP 0...100.0 °C Real setpoint R 0.1 -
009* OUT - Output status relay (see below) R Flag -
015* MOT_SET 0...1700 Motor speed (set) R 1 -
104* STAT - Flag status R Flag -
105 ALR_STAT - Flag alarms R Flag -
200 ADR 1...255 Device address (Note 1) R/W 1 1
201 PRG - Flag conguration R/W Flag 0
202 SPL 5.0...SPH °C Minimum setpoint R/W 0.1 16.0
203 SPH SPL...35.0 °C Maximum setpoint R/W 0.1 28.0
209 E_SAVING 0...8.5 °K Contact presence oset/stand-by R/W 0.1 0
210* MVV5 400...MVV3-4 Minimum speed in MIN and Night mode R/W 1 400
211* MVV4 MVV5...MVV2
Maximum speed in Night Mode and Mini-
mum in AUTO
R/W 1 550
212* MVV3 MVV5...MVV1
Maximum speed in MIN and Minimum in
MAX
R/W 1 680
230 MVVP3 MVV5...MVVP1
Maximum speed in MIN and Minimum in
MAX with Performance enabled
R/W 1 920
213* MVV2 MVV4...1500 Maximum speed in AUTO R/W 1 1100
234 MVVP2 MVV4...1500
Maximum speed in AUTO with Perfor-
mance enabled
R/W 1 1220
214* MVV1 MVV3...1500 Maximum speed in MAX R/W 1 1500
215* MVVP1 MVV1...1700
Maximum speed in MAX with Performance
enabled
R/W 1 1700
218* LLO 0.0...100.0 °C Minimum water for heating R/W 0.1 30.0
219* LHI 0.0...100.0 °C Maximum water for cooling R/W 0.1 20.0
221 ACL 0...32000 hours Maintenance frequency 0 excluded R/W 1 0
222 ACL_TIM 0...ACL Motor fan working hours count R/W 1 -
231 SP
SPL...SHP
SPL_W...SPH_W
Absolute setpoint value (Note 2) R/W 0.1 20.0
233 Man 0/3 (inv)/5 (est) Seasonal auto/manual R/W 1 3
242 OS1 -12.0...12.0 °K T1 air probe oset R/W 0.1 0
243* OS2 -12.0...12.0 °K H2 water probe oset R/W 0.1 0
244* OS3 -12.0...12.0 °K H4 water probe oset R/W 0.1 0
245 SPL_W 5.0...SPH_W °C WEB Minimum setpoint R/W 0.1 20.0
246 SPH_W SPL_W...40 °C WEB Maximum setpoint R/W 0.1 24.0
247 WEB - WEB Flag (see dedicated paragraph) R/W Flag 0
* Only for INN-FR-B32 board
Note 1: The device address can be set individually on various devices by writing it on register 200 or set manually via the keyboard
of the EKRTCTRL1 - EKWHCTRL1 kits (see paragraph 6).
Note 2: Absolute setpoint value from 5 to 40. For the setpoint, write the value within the selected scale.
