General Outline ESIE11-02
1–8 Part 1 – System Outline
3
11
4
5
1.3 Technical Specifications: EUWA*10-12KBZW1
Technical
specifications
The table below contains the technical specifications.
Model EUWAN10KBZW1 EUWAP10KBZW1 EUWAB10KBZW1 EUWAN12KBZW1 EUWAP12KBZW1 EUWAB12KBZW1
Nominal cooling
capacity
22.5 kW 26.5 kW
Nominal input
8.79 kW 8.74 kW 11.5 kW
Capacity steps
0-100%
Compressor
Type Hermetically sealed scroll
Speed 2900 rpm
Crankcase heater 50 W
No. x model (W1) 1 x JT265DA-YE 1 x JT335DA-YE
Evaporator
Type Brased plate-heat exchanger
No. x model 1 x AC70X-40HX 1 x AC70X-50HX
Min.water volume
in the system
(1)
108 l 126 l
Water flow rate Min.: 32 l/min
Max.: 129 l/min
Min.: 38 l/min
Max.: 152 l/min
Nominal water
flow
64 l/min 76 l/min
Nom. water
pressure drop
43 kPa 37 kPa
Insulation material Climaflex
Condenser
Type Cross fin coil Hi-X tubes and PE coated waffle louvre fins
Rows x stages x
fin pitch
2x50x2.0mm
Face area 1.970 m²
Nominal air flow 170 m³/min
Discharge Vertical
Fan type Direct drive
No. of fans 2
No. of motors x
output
1 x 190 kW and 1 x 230 kW 1 x 190 kW and 1 x 230 kW
Piping connections
Evap. water
in/outlet
FBSP 1-1/4”
Refrigerant circuit
Refrigerant type R-407C
Refrigerant
charge
4.6 kg 6.0 kg
Refrigerant control Thermostatic expansion valve
