Daikin EWAD620-C17C-SS - 2.4 Expansion I;O EXV Circuit #1 to #4 (POL94 U.00;MCQ)

Controller Inputs and Outputs ESIE10-01
3–60 Part 3 – Troubleshooting
3
1
3
4
5
2.4 Expansion I/O EXV Circuit #1 to #4 (POL94U.00/MCQ)
Analog inputs
Analog outputs
Digital inputs
Digital outputs
Stepper motor
output
# Description Signal Source Expected Range
X2 Suction Temperature NTC Thermister 10K@25°C) -50°C – 120°C
# Description Output Signal Range
Not Needed
# Description Signal Off Signal On
DI1 Low Pressure switch Fault No fault
# Description Output Off Output On
DO1 Liquid Line Solenoid Closed Solenoid Open
# Description
M1+
EXV Stepper Coil 1
M1-
M2+
EXV Stepper Coil 2
M2-
