The Digital Controller ESIE10-01
2–16 Part 2 – Functional Description
3
1
2
4
5
1.4.2 Set Point
Set point table The following set points are remembered during power off, are factory set to the Default value, and
can be adjusted to any value in the Range column.
Warning: These values are the default settings; however they might not be correct ones to provide a
correct operation of the unit in any given situation. All parameters and settings should be checked
during the commissioning by an authorized and skilled engineer.
Description Default Range
Unit SI
Manufacturing Location Not Selected Not Selected, Europe, USA
Unit Enable OFF OFF, ON
Unit Status after Power Failure OFF OFF, ON
Control source Local Local, Network
Available Modes Cool COOL
COOL/w GLYCOL
COOL/ICE w GLYCOL
ICE
TEST
Cool LWT 1 7°C See auto adjusted settings
Cool LWT 2 7°C See auto adjusted settings
Ice LWT -4°C -8 to 4°C
Startup Delta T 2.7°C 0 to 5°C
Shut Down Delta T 0.7°C 0 to 1.7°C
Stage Up Delta T (between compressors) 1°C 0 to 1.7°C
Stage Down Delta T (between compres-
sors)
0.5°C 0 to 1.7°C
Max Pulldown 1.7°C/min 0.3 to 2.7°C/min
Evap Recirc Timer 30 0 to 300 seconds
Evap Control #1 Only #1 Only, #2 Only, Auto,
#1 Primary, #2 Primary
LWT Reset Type NONE NONE, RETURN, 4-20mA, OAT
Max Reset 5°C 0 to 10°C
Start Reset Delta T 5°C 0 to 10°C
Start Reset OAT 23.8°C 10.0 – 29.4°C
Max Reset OAT 15.5°C 10.0 – 29.4°C
Soft Load Off Off, On
Begin Capacity Limit 40% 20-100%
Soft Load Ramp 20 min 1-60 minutes
Demand Limit Off Off, On
