Controller Inputs and Outputs ESIE10-01
3–62 Part 3 – Troubleshooting
3
1
3
4
5
2.6 Expansion I/O Fan Module Circuit #3 (POL945.00/MCQ)
Digital inputs
Digital outputs
# Description Output Off Output On
DI1 PVM/GFP Circuit #3 Fault No fault
# Description Output Off Output On
DO1 Circuit #3 Fan Step #1 Fan Off Fan On
DO2 Circuit #3 Fan Step #2 Fan Off Fan On
DO3 Circuit #3 Fan Step #3 Fan Off Fan On
DO4 Circuit #3 Fan Step #4 Fan Off Fan On
