ESIE10-01 General Outline
Part 1 – System Outline 1–67
3
1
4
5
Notes Cc (cooling capacity) – Pi (unit power input) – ELWT (evaporator leaving water temperature – Δt 5°C).
Data are referred to 0,0176 m
2
°C/kW evaporator fouling factor.
C18
4 1,692 455 1,646 497 1,590 541 1,517 590 1,399 656 1,278 647 1,085 600
5 1,738 463 1,692 505 1,634 550 1,558 599 1,433 664 1,279 641 1,097 597
6 1,786 470 1,737 513 1,678 559 1,600 609 1,460 669 1,285 636 1,098 588
7 1,833 477 1,784 521 1,722 567 1,643 618 1,483 672 1,290 630 1,108 584
8 1,882 485 1,831 529 1,767 576 1,686 628 1,485 666 1,293 623 1,109 575
9 1,931 493 1,878 538 1,812 585 1,728 638 1,492 662 1,298 616 1,117 569
10 1,980 501 1,926 546 1,858 594 1,771 647 1,497 657 1,310 613 1,123 563
11 2,031 509 1,974 555 1,904 604 1,815 657 1,501 650 1,308 603 1,128 557
12 2,081 517 2,023 564 1,951 613 1,859 668 1,507 645 1,317 598 1,132 550
13 2,133 525 2,072 573 1,998 623 1,903 678 1,507 636 1,325 593 1,139 544
14 2,185 534 2,122 582 2,045 633 1,948 688 1,519 633 1,332 587 1,152 541
15 2,237 543 2,172 591 2,093 643 1,993 699 1,520 625 1,338 581 1,157 534
C19
4 1,778 478 1,731 522 1,674 569 1,600 620 1,479 690 1,372 691 1,165 641
5 1,827 485 1,779 530 1,720 578 1,644 630 1,521 701 1,371 683 1,178 638
6 1,877 493 1,827 538 1,766 586 1,687 639 1,561 711 1,379 679 1,180 629
7 1,927 501 1,876 547 1,813 595 1,731 649 1,592 717 1,385 673 1,191 625
8 1,977 509 1,925 555 1,860 605 1,776 659 1,592 710 1,389 666 1,189 614
9 2,029 517 1,974 564 1,907 614 1,821 669 1,600 707 1,391 658 1,198 608
10 2,081 525 2,025 573 1,955 623 1,866 679 1,607 702 1,404 655 1,205 602
11 2,133 533 2,075 581 2,004 633 1,912 690 1,612 696 1,403 645 1,211 595
12 2,186 542 2,127 591 2,053 643 1,958 700 1,615 689 1,414 640 1,216 588
13 2,240 550 2,178 600 2,102 653 2,005 711 1,617 681 1,423 635 1,220 580
14 2,294 559 2,231 609 2,152 663 2,052 722 1,630 677 1,431 629 1,238 579
15 2,349 568 2,284 619 2,202 673 2,099 733 1,628 667 1,438 623 1,239 570
Size
ELWT
(°C)
Condenser Inlet Air Temperature (°C)
25 30 35 40 46 48 50
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
