ESIE10-01 General Outline
Part 1 – System Outline 1–69
3
1
4
5
Notes Cc (cooling capacity) – Pi (unit power input) – ELWT (evaporator leaving water temperature – Δt 5°C).
Data are referred to 0,0176 m
2
°C/kW evaporator fouling factor.
C12
4 1,120 267 1,089 292 1,057 316 1,019 342 958 376 919 395 874 415
5 1,154 271 1,123 296 1,090 321 1,050 347 988 381 949 400 882 412
6 1,189 275 1,158 300 1,124 325 1,083 352 1,019 386 978 405 888 409
7 1,225 279 1,192 304 1,158 330 1,116 356 1,050 392 1,008 411 894 404
8 1,261 283 1,228 308 1,192 334 1,149 361 1,081 397 1,039 417 898 399
9 1,298 286 1,264 313 1,227 339 1,183 366 1,113 402 1,070 422 901 393
10 1,335 291 1,301 317 1,262 344 1,217 372 1,145 408 1,101 428 912 390
11 1,374 295 1,338 321 1,299 348 1,251 377 1,178 414 1,133 434 913 384
12 1,411 299 1,376 326 1,335 353 1,286 382 1,211 419 1,156 437 922 380
13 1,449 303 1,413 331 1,372 358 1,322 387 1,244 425 1,162 433 920 372
14 1,488 307 1,451 335 1,409 363 1,358 393 1,278 431 1,166 428 927 368
15 1,528 312 1,489 340 1,446 368 1,394 398 1,313 437 1,179 426 934 363
C13
4 1,237 295 1,203 321 1,167 348 1,124 377 1,057 414 1,014 435 964 457
5 1,275 299 1,241 326 1,204 353 1,160 382 1,090 420 1,046 441 973 455
6 1,315 303 1,279 331 1,241 358 1,196 387 1,124 426 1,079 447 976 452
7 1,354 307 1,318 335 1,279 363 1,232 393 1,158 432 1,112 453 976 448
8 1,395 312 1,358 340 1,318 368 1,269 398 1,194 437 1,146 459 980 445
9 1,436 316 1,398 345 1,357 374 1,307 404 1,229 444 1,181 465 983 441
10 1,478 321 1,439 350 1,397 379 1,345 410 1,265 450 1,216 472 990 438
11 1,521 325 1,481 355 1,437 384 1,384 415 1,302 456 1,251 478 990 433
12 1,564 330 1,523 360 1,478 390 1,423 421 1,338 462 1,273 480 993 429
13 1,607 335 1,565 365 1,519 395 1,463 427 1,376 469 1,278 478 1,001 427
14 1,651 340 1,608 370 1,561 401 1,503 433 1,414 475 1,282 475 1,003 422
15 1,695 345 1,652 375 1,603 407 1,544 440 1,452 482 1,285 471 1,009 419
C14
4 1,344 321 1,307 350 1,268 379 1,222 410 1,149 451 1,103 474 1,049 498
5 1,386 325 1,348 355 1,308 385 1,261 416 1,185 457 1,138 480 1,058 496
6 1,428 330 1,390 360 1,349 390 1,300 422 1,222 464 1,174 487 1,065 494
7 1,470 334 1,432 365 1,390 396 1,339 428 1,260 470 1,210 493 1,062 488
8 1,514 339 1,474 370 1,431 401 1,380 434 1,298 477 1,247 500 1,067 485
9 1,558 344 1,517 375 1,473 407 1,420 440 1,336 483 1,284 507 1,070 481
10 1,603 349 1,561 380 1,516 412 1,461 446 1,375 490 1,322 514 1,082 479
11 1,649 354 1,606 386 1,559 418 1,502 452 1,414 496 1,360 521 1,082 474
12 1,694 359 1,652 391 1,603 424 1,544 458 1,454 503 1,388 524 1,081 468
13 1,740 364 1,697 397 1,648 430 1,587 465 1,494 510 1,394 522 1,090 465
14 1,787 369 1,742 402 1,692 436 1,630 471 1,535 517 1,399 519 1,097 462
15 1,834 374 1,788 408 1,736 442 1,674 478 1,576 524 1,402 515 1,104 458
Size
ELWT
(°C)
Condenser Inlet Air Temperature (°C)
25 30 35 40 46 49 52
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
