ESIE10-01 General Outline
Part 1 – System Outline 1–71
3
1
4
5
Notes Cc (cooling capacity) – Pi (unit power input) – ELWT (evaporator leaving water temperature – Δt 5°C).
Data are referred to 0,0176 m
2
°C/kW evaporator fouling factor.
C11
4 1,101 265 1,071 290 1,036 315 992 342 922 378 878 398 704 353
5 1,135 269 1,104 294 1,067 320 1,022 347 950 384 899 401 706 346
6 1,169 274 1,137 299 1,100 325 1,053 353 979 390 906 398 714 343
7 1,204 278 1,171 304 1,132 330 1,084 358 1,008 396 904 390 714 335
8 1,239 283 1,205 309 1,165 336 1,116 364 1,037 402 909 385 721 331
9 1,275 288 1,240 314 1,199 341 1,147 370 1,067 408 920 384 727 326
10 1,311 292 1,275 319 1,232 346 1,179 376 1,097 414 923 377 732 321
11 1,348 297 1,311 324 1,267 352 1,212 382 1,127 421 925 370 736 316
12 1,385 302 1,347 330 1,301 358 1,244 388 1,133 418 934 367 740 311
13 1,422 307 1,383 335 1,336 364 1,278 394 1,138 413 933 359 742 305
14 1,460 312 1,419 340 1,372 370 1,311 400 1,142 408 940 355 754 304
15 1,498 318 1,456 346 1,407 376 1,345 407 1,144 401 947 351 755 298
C13
4 1,216 292 1,182 319 1,143 347 1,094 377 1,017 416 969 438 758 398
5 1,254 297 1,219 324 1,178 352 1,128 383 1,048 423 988 440 764 395
6 1,292 302 1,256 330 1,214 358 1,162 389 1,080 429 991 438 768 391
7 1,331 307 1,294 335 1,251 364 1,197 395 1,112 436 993 434 771 386
8 1,371 312 1,332 341 1,288 370 1,232 401 1,144 443 997 431 773 381
9 1,411 317 1,371 346 1,325 376 1,267 408 1,177 450 1,000 427 779 378
10 1,451 323 1,410 352 1,362 382 1,303 414 1,211 457 1,002 423 783 374
11 1,493 328 1,450 358 1,401 388 1,339 421 1,241 462 1,007 420 787 370
12 1,534 334 1,491 364 1,439 395 1,376 428 1,247 460 1,012 416 790 365
13 1,576 339 1,532 370 1,479 401 1,413 435 1,246 456 1,015 412 792 360
14 1,618 345 1,573 376 1,518 408 1,451 442 1,249 452 1,022 409 799 358
15 1,661 351 1,614 382 1,558 415 1,489 449 1,251 448 1,024 404 804 354
C14
4 1,322 318 1,285 347 1,243 378 1,190 410 1,106 453 1,054 477 826 434
5 1,363 323 1,325 353 1,281 384 1,226 417 1,140 460 1,079 481 836 432
6 1,404 329 1,365 359 1,320 390 1,263 423 1,174 468 1,078 477 836 426
7 1,446 334 1,406 365 1,359 396 1,301 430 1,209 475 1,084 474 844 423
8 1,488 339 1,447 371 1,399 403 1,339 437 1,244 482 1,089 471 842 416
9 1,531 345 1,488 377 1,439 409 1,377 444 1,280 490 1,093 467 848 412
10 1,574 351 1,531 383 1,480 416 1,416 451 1,317 497 1,095 463 853 408
11 1,619 357 1,574 389 1,521 423 1,455 458 1,353 505 1,096 457 857 403
12 1,663 363 1,617 396 1,562 429 1,494 466 1,360 503 1,106 455 860 398
13 1,708 369 1,661 402 1,604 436 1,534 473 1,355 496 1,104 449 862 393
14 1,753 375 1,705 409 1,647 444 1,574 481 1,358 492 1,113 446 876 392
15 1,798 381 1,749 415 1,689 451 1,615 488 1,361 488 1,120 442 876 386
Size
ELWT
(°C)
Condenser Inlet Air Temperature (°C)
25 30 35 40 46 49 52
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
Cc
(kW)
Pi
(kW)
To Next Page
