3
2
• Split - Sky Air • FAQ-C
3
• Indoor Unit • FAQ-C
2 Specifications
Standard Accessories : Installation and operation manual; Quantity : 1;
Standard Accessories : Installation panel;
Standard Accessories : Insulation tape;
Standard Accessories : Screws;
Standard Accessories : Clamps;
Standard Accessories : Screw cover;
2-1 Technical Specifications FAQ71C FAQ100C *FAQ125C
Power input Cooling Nom. kW 0.051 0.061 -
Heating Nom. kW 0.068 0.061 -
Casing Colour Fresh White -
Material Resin -
Dimensions Unit Height/Width/
Depth
mm 290/1,050/238 340/1,200/240 340/1,200/240
Packed unit Height/Width/
Depth
mm 366/1,147/337 429/1,310/325 -/-/-
Weight Unit kg 13 17 17
Packed unit kg 19 24 -
Heat exchanger Length mm 863 963 -
Rows Quantity 2 -
Fin pitch mm 1.2 -
Passes Quantity 4 6 -
Face area m² 0.279 0.347 -
Stages Quantity 18 20 -
Empty tubeplate
hole
Quantity 0 -
Fin Type Cross fin coil (Multi slit fins and Hi-XB tubes) -
Fan Type Cross flow fan -
Quantity 1 -
Air flow rate Cooling High m³/min 18 26 -
Nom. m³/min 16 23 -
Low m³/min 14 19 -
Heating High m³/min 18 26 -
Nom. m³/min 16 23 -
Low m³/min 14 19 -
Fan motor Model QCL9663MA QCL1096M -
Speed Steps 3 -
Output High W 48 64 -
Phase x Voltage V DC310 DC325 -
Full load amps
(FLA)
Cooling A 0.3 0.4 -
Heating A 0.4 -
Sound power level Cooling dBA 61 65 -
Heating dBA 61 65 -
Sound pressure level Cooling High/Nom./Low dBA 45/42/40 49/45/41 -/-/-
Heating High/Nom./Low dBA 45/42/40 49/45/41 -/-/-
Control systems Infrared remote control BRC7EB518 -
Wired remote control BRC1D52 / BRC1E52A/B -
Refrigerant Type R-410A -
Piping connections Liquid Type/OD mm Flare connection/9.52 /-
Gas Type/OD mm Flare connection/15.9 /-
Drain VP13 (I.D. 13/O.D. 18) -
Heat insulation Foamed polystyrene / Foamed polyethylene -
2-2 Electrical Specifications FAQ71C FAQ100C *FAQ125C
Power supply Phase 1~ 1~
Frequency Hz 50/60 50/60
Voltage V 220-240/220 220-240/220
